PET Expandable Braided Sleeving

CYG-PETN

PET Expandable Braided Sleeving

  • Cross-linked modified fluoropolymer
  • Shrink ratio: 2:1
  • High-temperature resistance, transparent, and flame retardant
  • Flexible (-55℃~150℃) and semi-rigid (-55℃~175℃)
Request a Quote
Applications
  • Our PET expandable braided sleeving, made from environmentally friendly and halogen-free PET monofilaments, meets the abrasion resistance requirements of various industrial applications.
  • Its unique braided structure can expand to more than 1.5 times its diameter, providing high flexibility. It is ideal for securing and protecting wires, cables, and other items, such as industrial wire bundling and tubing protection.
Features
  • Shrink ratio: 2:1
  • High-temperature resistance, transparent, and flame retardant
  • Flexible (-55℃~150℃) and semi-rigid (-55℃~175℃)
Materials
Raw Material Purpose Content
Polyethylene Terephthalate (PET) [-CH2-CH2-O-C(=O)-ph-C(=O)O-]n Main material 88%
Melamine Phosphate (MP) C3H6N6.(H3PO4)n Flame retardant 10%
Pigment Toner(Fe3O4 ) Colorant 20%
Technical Data
Properties Test Method Performance
Flammability UL 1441/UL 94 VW-1
Tensile strength of single filament ASTMD2256 250mm/min PET≥30.4N
Melting point ASTMD3418 / GMW15608 240℃±10℃
Heat shrinkage 177℃ 3min PET≤5.5%
Heat aging test GMW14327 150℃ 1000H No cracking
Low temperature flexibility GMW14327 -40℃ 4H No cracking
Fluid resistance IRM903 oil GMW14327 No cracking or degradation
Power steering oil
Engine oil
Transmission fluid
Brake fluid
Heat shock 260℃×16H; Ambient temperature ×4H; -40℃×4H; 10 cycles No cracking
Operating temperature MIL-STD-105E -40℃-150℃
Abrasion resistance ISO 6722-1 ≥15000 cycles No cracking
